Amplifier/network separator RM-07
Amplifier / network separator RS-485.
The RM-07 module serves as a signal amplifier of Modbus RTU transmission and as a galvanic separator of the RS-485 network.
The RM-07 module serves as a signal amplifier of Modbus RTU transmission and as a galvanic separator of the RS-485 network.
It amplifies the signal enabling extension of the bus range and connecting more devices. It can also be used for branching lines and protecting them by electromagnetic interference.
Supported speeds [kbps]:
1200, 2400, 4800, 9600, 14400, 19200, 28800, 38400, 56000, 115200.
The module amplifies the signal in both directions. Galvanic separation is between port 10-12 and port 4-6 with power supply 1-3.
Reinforcement
For signal amplification with long communication networks.
Extension
For extending the bus by another group of 32 receivers. Up to 4 groups can be extended for a transmission speed of 9600.
Isolation
To protect the group of receivers from interference generated on the side of long communication networks.
Ramification
To reduce the influence of interference caused by branching of long signal lines.
- Power supply voltage
- 9÷30 V DC
- Speed
- 1200÷115200 bps
- System current
- 25 mA
- Galvanic separation
- 1 kV
- Terminal
- pluggable terminal blocks 2,5 mm²
- Tightening torque
- 0,4 Nm
- Working temperature
- -25 ÷ 50 °C
- Dimensions
- 1 module (18 mm)
- Assembly
- on rail 35 mm
- Ingress Protection Marking
- IP20
