Fluid level control relay PZ-832 RC

PZ-832RC, 5908312594369

Two-positions, with emergency states.
Fluid level control relays PZ-832 is devised to detect the presence of conductive liquids reaching the level of the sensor.




Functioning
Relay control MAX and MIN  statues set by user of controlled fluid. After the liquid level decreases to MIN (i.e. electrodes MIN and COM spaced), the MIN joint is switched to position 17-16 (FILLING), whereas the MAX joint remains in position 21-22. On the other hand, when the MAX liquid level is reached (MAX and COM electrodes shorted), the relay's MIN joint will be switched to position 17-18 (EMPTYING), whereas the MAX into position 21-20. Emergency state: ALmin (dry running) - after the liquid level decreases to ALmin (i.e. electrodes MIN and COM spaced), the ALmin joint is switched to position 12-11; ALmax (overflow) after level is reached Almax (ALmax and COM electrodes shorted), the relay's Almax joint will be switched to position 15-14. .


ATTENTION!
The electrode probe is connected by means of a cable with wire diameter up to 1mm  and maximum length of 100 m.


ATTENTION!
Joints 4-5-6 -7-8 galvanic separated.


PZ-832RC
Power supply voltage
230 V AC
The executive element
4 x relay
Contact configuration
4 × NO/NC
Separation of the contact
YES
Load current MIN and MAX
2 x 16 A
Load current ALmin and ALmax
2 x 8A
Delay of operation
1÷2 s
Sensitivity - adjustable
1÷100 kΩ
Współpraca z wodą deszczową
NIE
Voltage of measuring outputs
6 V
Type of flood probe
5 x PZ2
Probe clamps
separated from the transformer network
Terminal
pluggable terminal blocks 4,0 mm²
Tightening torque
0,5 Nm
Power consumption
1,1 W
Working temperature
-25 ÷ 50 °C
Dimensions
5 modules (87,5 mm)
Assembly
on rail 35 mm
Ingress Protection Marking
IP20
