GPS LOCATION TRANSDUCER MB-GPS-1
The transmitter is equipped with a standard positioning module of the GPS system (Global Positioning System).
Purpose
The MB-GPS-1 transducer, based on the received signal, provides
current data for its location:
* geographical coordinates (length/width);
* data (year/month/day);
* time (hour/minutes/seconds);
* altitude (meters above the sea level).
The device is equipped with the location module of the GPS (Global Positioning System) and the GLONASS system (Russian: ГЛО-НАСС, Глобальная навигационная спутниковая система, Globalnaja nawigacionnaja sputnikowaja sistiema). The device, based on one of these signals, provides current data for its location: geographical coordinates (length and width), date and time.
If the satellite signal is lost, the device continues the countdown in the internal clock. When the satellite signal is re-established, the internal clock time is synchronized to the received value. This operation allows to synchronize PCZ-527 time with GPS/GLONASS reference clocks and set clock parameters precisely, eliminating the need to manually enter the location.
The MB-GPS-1 transducer, based on the received signal, provides
current data for its location:
* geographical coordinates (length/width);
* data (year/month/day);
* time (hour/minutes/seconds);
* altitude (meters above the sea level).
The device is equipped with the location module of the GPS (Global Positioning System) and the GLONASS system (Russian: ГЛО-НАСС, Глобальная навигационная спутниковая система, Globalnaja nawigacionnaja sputnikowaja sistiema). The device, based on one of these signals, provides current data for its location: geographical coordinates (length and width), date and time.
If the satellite signal is lost, the device continues the countdown in the internal clock. When the satellite signal is re-established, the internal clock time is synchronized to the received value. This operation allows to synchronize PCZ-527 time with GPS/GLONASS reference clocks and set clock parameters precisely, eliminating the need to manually enter the location.
- Power supply voltage
- 9÷30 V DC
- ports
- RS-485
- Communication protocol
- MODBUS RTU
- The type of work
- SLAVE
- Baudrate
- 1200÷115200 bit/s
- Data bits
- 8
- Stop bits
- 1 / 1.5 / 2
- Bits of parity
- EVEN / ODD / NONE
- Address
- 1÷247
- Power consumption (max)
- 40 mA
- Terminal
- pluggable terminal blocks 2,5 mm²
- Tightening torque
- 0,4 Nm
- Power consumption
- 0,3 W
- Working temperature
- -40÷70°С
- Dimensions
- 60 mm x 85 mm x 35 mm
- Assembly
- on wall
- Ingress Protection Marking
- IP65 - hermetic
