Electricity consumption meter, 3-phase, resetable LE-03-FPV-RST
The LE-03-FPV-RST meter is an electronic, legalised (MID declaration), 3-phase, 4-wire electricity meter for direct metering.
The meter is capable of measuring both active energy consumed and energy given up, making it ideal for monitoring energy production and consumption in photovoltaic installations.
The LE-03-FPV-RST is also equipped with an additional erasable energy meter, facilitating direct observation of the increase in energy since the previous meter reset, and an illuminated reading field.
MID Directive 2014/32/EU
Certificate 0120/SGS0670
Under the influence of the flowing current and applied voltage, the meter precisely measures energy and active power. The current data is displayed on a 7-character LCD. Energy increments (separately for imported and exported energy) are additionally indicated by blinking LEDs on the front of the unit. The meter is also equipped with a pulse output to indicate a change in total energy (total energy = imported energy + exported energy).
- Type
- three-phase
- Installation
- 3-phase, 4-wire
- ports
- RS-485
- Communication protocol
- MODBUS RTU
- Compatibility
- Dyrektywa MID 2014/32/EC, 0120/SGS0306, Norma EN50470-1/3
- Reference voltage
- 3×230/400 V
- Current current
- 5:00 AM
- Maximum current
- 80 A
- The minimum measured current
- 0,003 A
- Counter's own consumption
- 10 VA; 2 W
- Scope of indication of the abacus
- 8 cyfr
- Reading signaling
- 2 x LED
- Pulse output SO + SO-
- open collector
- Connection voltage SO + SO-
- max. 30 V DC
- Connection current SO + SO-
- max. 27 mA
- Accuracy class
- B
- Nominal frequency
- 50 Hz
- Insulation protection class
- II class
- The number of LCD characters
- 8
- overload
- 30×lmax/10 ms
- Insulation
- 4 kV/1 min.; 6 kV/1 μs
- Voltage measured L-N
- 100÷289 V AC
- Voltage measured L-L
- 173÷500 V AC
- Stop bits
- 1
- Terminal
- pluggable terminal blocks 25 mm²
- Working temperature
- -25 ÷ 50 °C
- Dimensions
- 76×100×65 mm (4,5 modułu DIN)
- Assembly
- on rail 35 mm
- Ingress Protection Marking
- IP51
- Prędkość transmisji
- 1200, 2400, 4800, 9600 bps
- Parzystość
- EVEN
