LK-702 2-state indicator light
Signaling lamp LK-702 is used to visually signal the states of specified circuits or receivers, such as work/break, open/closed, etc.
The small size of the housing (width of 6.2 mm) allows to save space in the switchboard.
The status of the controlled circuit or receiver is indicated by the illumination of the corresponding LED connected in parallel to this circuit or receiver.
In the event that an overcurrent fuse equal to or greater than 25 A is installed before the lamp connection point, the lamp connection circuit should be fused with a fuse no greater than 6 A.
- Power supply voltage
- 2× 230 V+N
- Power control
- 2 × LED
- LED colors
- 2× LED (zielony, czerwony)
- Rated current
- 1 mA/kanał
- Terminal
- pluggable terminal blocks 2,5 mm²
- Tightening torque
- 0,4 Nm
- Power consumption
- 0,15 W/kanał
- Working temperature
- -30÷50°C
- Dimensions
- 1/3 modułu (6,2 mm)
- Assembly
- on rail 35 mm
- Ingress Protection Marking
- IP20
